PRODUCT FAMILY
1000W Rated Compact Inverter Generator
1 listed configuration · Family DUP-IG-001
A compact 1,000 W rated gasoline inverter generator with manual start, single-phase output and a 3 L fuel tank.
| Primary category | Power Generation & Engines |
|---|---|
| Product type | Inverter Generators |
| Public family | Portable Inverter Generators |
| Configurations | 1 |
| Power source | Gasoline |
| Battery platform | Not applicable |
| Motor type | Configuration to confirm |
Voltage, plug, exact configuration, compliance documents, packaging and branding are confirmed for the destination market before quotation or order placement. The commercial terms below are planning references; final terms are confirmed in the quotation.
QUICK FAMILY COMPARISON
Compare nearby Inverter Generators options
Review the closest product families, then add the relevant options to one inquiry.
| Family | Product | Key specifications | Power | Inquiry |
|---|---|---|---|---|
| DUP-IG-001 Current page | 1000W Rated Compact Inverter Generator | Frequency: 50 Hz Running power: 1,000 W | Gasoline | Current family |
| DUP-IG-002 | 1800W Rated Portable Inverter Generator | Frequency: 50 Hz Running power: 1,800 W | Gasoline | |
| DUP-IG-003 | 2000W Rated Portable Inverter Generator | Frequency: 50 Hz Running power: 2,000 W | Gasoline | |
| DUP-IG-004 | 3.0 kW Rated Compact Inverter Generator | Frequency: 50 Hz Running / maximum power: 3,000 W / 3,200 W | Gasoline |
COMMERCIAL TERMS
Planning reference for this family
- Typical MOQ
- 100 units Power Generation & Engines
- Sample lead time
- Around 7 days After specifications are confirmed
- Production lead time
- Around 30 days After sample and packaging approval
- OEM
- Welcome Scope confirmed for each program
These are planning references for typical standard configurations, not a binding quotation. MOQ may vary with the model, OEM scope, customized colors, packaging, voltage, plug type and certification requirements. The final MOQ and schedule are confirmed for each quotation and order.
CONFIGURATION MATRIX
Choose the right configuration
Use the DUPOW configuration reference in your inquiry. Final market version, accessories and packaging remain subject to confirmation.
| Product view | Inquiry reference | Configuration | Reviewed specifications |
|---|---|---|---|
 | DUP-IG-001Lead configuration | Current reviewed configuration | Frequency: 50 HzRunning power: 1,000 WMaximum power: 1,100 WEngine: 56 cc four-stroke air-cooledStarting method: ManualPower speed: 3,500–5,000 / 4,100–5,000 rpmRunning time at 50% load: 5 hNoise at 50% load / 7 m: 64 dBRated current: 4.3 APhase: SingleOil: SAE 10W-30 / 0.25 LFuel capacity: 3 LBattery: NoPackage: Outer carton: 470 × 320 × 440 mm. Quantity: 1 set/ctn. Net / gross weight: 12 / 14 kg. Loading: 430 sets/20 ft; 875 sets/40 ft; 1,050 sets/40 HQ.Certification documentation available upon request. |
